SKU: Hybond-616-Ultrasonic-Bonder Equipment Type: Brand:


HYBOND’s Model 616 ultrasonic single channel peg bonder has

been designed to perform ultrasonic attachment of insulated or

bare wire/ribbon. Applications include hard disk head stack

assemblies, head gimbal assemblies, microwave and

sensor circuits.


Bond level sensor system which stops Z

movement at bonding level and activates bond force/ultrasonics sequence.

Front panel control of bond head search height

which indexes from last bonding level.

Bond head vertical movement controlled by

push button or electrical foot actuation (manual or automatic).

Electrical chassis with modular circuit boards

for control functions to allow simplified

trouble shooting and repair.

HYBOND standard work platform with 4:1


Force system factory adjusted to prevent


Anti-static equipment enclosure.

Interested in this Equipment? Contact Us Today!
